Ultrasonic Sensor - US Q12 M 400 G3-T4

Part Number: US Q12 M 400 G3-T4

Article Number: 210964

We’re known for our depth of knowledge. If you’re looking for a new supplier of sensors for factory automation, contact us today.

Contact Us

Technical Details

Operating principle Ultrasonic sensor, Ultrasonic barrier
Nominal switching distance (Sn) 400 mm
Assembly distance (sensor to sensor) 250 mm
Service voltage 18 … 30 V DC
Switching output Push-pull, 150 mA, NO/NC
Interface IO-Link (V1.1, COM2 38.4 kBd, Smart Sensor Profile)
Voltage drop (max.) 2 V
Housing material Aluminum (Anodized)
Ambient temperature during operation -25 … +70 °C
Protection type IP 67
Connection Connector, M8, 4-pin
