Fork Light Barrier - OGU 051/125 VP3K-TSSL

Part Number: OGU 051/125 VP3K-TSSL

Article Number: 201284

We’re known for our depth of knowledge. If you’re looking for a new supplier of sensors for factory automation, contact us today.

Contact Us

Technical Details

Operating principle Optical
Transmitter light source LED
Fork opening 50 mm
Service voltage 10 … 35 V DC (Supply Class 2)
No-load current (max.) 30 mA
Switching output pnp, 200 mA, NO/NC
Housing material Aluminum (Anodized)
Size 70 x 150 x 10 mm
Ambient temperature during operation -10 … +60 °C
Connection Connector, M8, 3-pin
