SK-TPN-10
Part Number: SK-TPN-10
Article Number: 201637
Technical Details
| Component | Sensor clamp |
|---|---|
| Green | Service voltage |
| No Load Current (max.) | 22.0 mA |
| Pulse Stretching | 1000.0 ms 10000.0 ms |
| Red | pnp closer-NO |
| Service Voltage | 10 ... 30.0V DC |
| Short Circuit Protection | no |
| Switching Frequency | 20000.0 Hz |
| Switching Output | pnp/npn 100.0 mA NO/NC |
| Yellow | pnp opener-NC |
