MZES 3.9 PS-K0.6-TSSL

Ambient Temperature During Operation	-20.0 ... 70.0°C
Connection	Pigtail 0.6 m M8
Connection Cable	TK ...
Current Carrying Capacity	100.0 mA not short-circuit-proof polarity-safe
Cylinder Groove	C-groove 3.9 mm insertion in lateral direction of groove
Housing Material	Stainless steel;Plastic V2A 1.4301 / AISI 304
Illumination Time Pulse	1.0
Insulation Voltage Endurance	500.0 V
Material Of Cable	TPU
Mounting	Locking screw
No Load Current (max.)	12.0 mA
Protection Class	III, operation on protective low voltage
Protection Type	IP 67
Reproducibility	< 0.1 mm
Service Voltage	10 ... 35.0V DC
Switching Capacity	3 < W 30 V, 100 mA
Switching Frequency	1000.0 Hz
Switching Output	pnp NO
Voltage Drop (max.)	2.0 V
Yellow	Output signal
